1*2.5GE+3*GE+1*USB3.0+WiFi6
10G EPON or XG-PON or XGS-PON ONU PTF4814X
1. Overview
FIBERWAYPTF4814X(1*2.5GE+3*GE+1*USB3.0+WiFi6) 10G EPON /XG(S)PON ONU adopts the latest WiFi 6(AX3000) technology, equipped with IEEE 802.3av(10G-EPON)/ITU-T G .987(XG-PON)/ITU-T G.9807.1 (XGS-PON) PON interface and IEEE802.11ax(WiFi 6) interface. Itsupports the full Triple Play of services enabling Data, Voice and Video services through Ethernet, Wi-Fi, FXS and USB standard interfaces, help Internet Service Providers to deliver internet service more than 2.5Gbps which is limited by GPON.
PTF4814X built-in Ethernet LAN ports, one 2.5GE BASE-T port and 3x1GE BASE-T ports support ultrafast device connection, and includes powerful and enhanced WLAN interface based on MU-MIMO OFDMA 2x2 2.4GHz MIMO and 5Ghz 2x2 MIMO Wi-Fi antennas supporting 802.11a/b/g/n/ac/ax standards over 2.4GHz and 5GHz wireless frequency bands for Internet application such as video, email, web surfing, files upload/download and online game.
2. Features
Ø LatestWiFi 6(AX3000)technology
Ø Bridging and routing modes can be set
Ø Gigabit WiFi6 2.4GHz & 5GHz Dual Band Speed up to 1.5/1.8/3 Gbps
Ø 2.5Gb RJ45 connector for higher bandwidth transmission, such as connecting to a WiFi6 router
Ø USB3.0 Interface for Shared Storage/Printer
Ø Support loop detection, IGMP snooping
Ø 802.1Q VLAN, QinQ, Cos, DSCP, QoS for priority of service
Ø Support port speed, storm suppression
Ø Can be used in a wide temperature environment
Ø SupportIPv4/IPv6 Stack
Ø Powerful firewall function, support remote software upgrading
|
Description |
Unit |
Value |
Conditions / Notes |
|
PON |
|||
|
PON standard |
|
10G EPON IEEE 802.3av, XG(S)-PON ITU-T G.987 /ITU-T G.9807.1 |
|
|
Optical interface |
|
10G PON port: Class B+ SC single mode, SC/UPC connector TX optical power: 8dBm RX sensitivity: -29.5dBm Overload optical power: -7dBm Transmission distance: 20km |
|
|
Wavelength |
nm |
10G EPON: DS 1577nm/US 1310nm XG(S)-PON:DS 1577nm/US 1270nm |
|
|
User interface |
|
1*2.5GE, Auto-negotiation,RJ45 ports 3*GE, Auto-negotiation,RJ45 ports 1*USB3.0 |
|
|
Antenna |
|
4 ×5dBi external antennas |
|
|
USB |
|
1×USB 3.0 for Shared Storage/Printer |
|
|
Button |
|
Reset |
|
|
Indicators |
|
PON/LOS, WAN, USB, PHONE, WIFI |
|
|
Function Data |
|||
|
Management |
|
WEB/TELNET/OAM/OMCI/TR069 |
|
|
Internet connection |
|
Support Bridge/Router mode |
|
|
Firewall |
|
DDOS, Filtering Based on ACL/MAC/URL |
|
|
Multicast |
|
IGMP v1/v2/v3, IGMP snooping MLD v1/v2 snooping |
|
|
WIFI |
|
Wi-Fi 6: 802.11a/n/ac/ax 5GHz & 802.11g/b/n/ax 2.4GHz WiFi Encryption:WEP-64/WEP-128/ WPA/WPA2/WPA3 Support OFDMA, MU-MIMO, Dynamic QoS, 1024-QAM Smart Connect for one Wi-Fi name - One SSID for 2.4GHz and 5GHz dual band |
|
|
VLAN |
|
802.1D&802.1ad bridge, 802.1p Cos,802.1Q VLAN |
|
|
L3 |
|
IPv4/IPv6, DHCP Client/Server,PPPoE, NAT, DMZ, DDNS |
|
|
Firewall |
|
Anti-DDOS, Filtering Based on ACL/MAC /URL |
|
|
Environmental Specifications |
|||
|
Operating condition |
℃ |
Operating temp: 0~ +55°C Operating humidity: 5~90% (non-condensed) |
|
|
Storing condition |
℃ |
Storing temp: -30 ~ +60°C Storing humidity: 5 ~ 90% (non-condensed) |
|
|
Power supply |
V |
DC 12V/2A, external AC-DC power adaptor |
|
|
Power consumption |
W |
≤24W |
|
|
Mechanical Specifications |
|||
|
Dimension (LxWxH) |
mm |
239x140x42 |
|
|
Weight |
kg |
0.43 |
|
|
Model |
Product Description |
Note |
|
PTF4814X-XE |
10G EPON，1*2.5GE+3*GE+USB3.0+WiFi 6(AX3000) |
|
|
PTF4814X-XG |
XG-PON，1*2.5GE+3*GE+USB3.0+WiFi 6(AX3000) |
|
|
PTF4814X-XGS |
XGS-PON，1*2.5GE+3*GE+USB3.0+WiFi 6(AX3000) |
|
