1GE HGU XPON ONU
PTF2351
Product Description:
FIBERY PTF is 1GE XPON (THGPON and E2PON) for 1GE XPON (and E2PON) calls. Telephony access needs of dual network operators, services or business operators. FTTD (TH family) XPON high quality monitoring XPON high It has excellent performance, performance, performance, high quality, high quality, in line with technology. Its management and service performance requirements. Fully meet the technical standard 802.3ah technical standard.
It can also be used in a warm environment, and also has a firewall and wide function.
features:
Ø HGU ONU, bridging and routing mode can be set
Ø Modular dual ONU for popular EPON and GPON OLT
Ø Support loop detection, IGMP, IGMP snooping
Ø 802.1Q VLAN, QinQ, Cos, DSCP, QoS service priority
Ø Support port, support port
Ø Support Telnet, CLI, OMCI/OAM and Web management
Ø Support NAT, firewall function
Ø Support remote software upgrade
|
project |
unit |
Specification |
|
PON standard. |
|
EPON IEEE802.3ah、GPON ITU-T G.984.x |
|
Optical interface |
|
SC/PC connector, 1 GPON/EPON interface (EPON PX20+ and GPON Class B+) Receiving sensitivity: ≤-28dBm Transmitting optical power: 0 ~ +4dBm Transmitting distance: 20KM |
|
speed |
Gbps |
GPON: Upstream 1.25Gbps, Downstream 2.5Gbps; EPON: Symmetrical 1.25Gbps |
|
wavelength |
Nano |
send 1310, receive 1490 |
|
interface |
data |
1*10/100/1000Mbps adaptive Ethernet interface, full/half duplex, RJ45 connector |
|
wireless |
Compliant with IEEE802.11b/g/n, 300Mbps |
|
|
index |
lead |
SYS、REG、LINK/ACT |
|
operating conditions |
℃ |
Operating temperature: -5 ~ +55 |
|
Storage Conditions |
℃ |
Storage temperature: -30 ~ +60 |
|
humidity |
% |
10~90 (non-condensing) |
|
power supply |
five |
DC 12V, 0.5A adapter |
|
energy consumption |
W |
≤4 |
|
aspect |
mm |
86mm×85mm×25mm(L×W×H) |
|
net weight |
Kilogram |
0.1 |
Transport Packaging:
|
describe |
quantity |
Wig H T |
carton size |
|
Transport Packaging |
1/box |
0.18kg/carton |
110mm*106mm*58mm |
|
100 pcs/box |
19kg/carton |
565mm*540mm*245mm |
